Schneider ABL8MEM24012 Regulated SMPS - 1 or 2-phase - 100..240 V AC - 24 V - 1.2 A

Main
range of product	Phaseo
product or component type	Power supply
power supply type	Regulated switch mode
input voltage	100...240 V AC phase to phase, terminal(s): L1-L2 100...240 V AC single phase, terminal(s): N-L1 120...250 V DC
output voltage	24 V DC
rated power in W	30 W
input protection type	Integrated fuse (not interchangeable)
power supply output current	1.2 A
output protection type	Against short-circuits
ambient air temperature for operation	-25...55 °C without 55...70 °C with

Complementary
input voltage limits	85...264 V
network frequency	47...63 Hz
inrush current	20 A
cos phi	0.5
efficiency	82 %
output voltage limits	22.2...28.8 V adjustable
power dissipation in W	6.6 W
current consumption	0.4 A at 240 V 0.65 A at 100 V
line and load regulation	+/- 3 %
residual ripple	250 mV
holding time	>= 10 ms at 100 V >= 150 ms at 230 V
connections - terminals	Screw type terminals for input connection, connection capacity: 2 x 0.14...2 x 2.5 mm² AWG 26...AWG 14 Screw type terminals for output connection, connection capacity: 4 x 0.14...4 x 2.5 mm² AWG 26...AWG 14
marking	CE
mounting support	35 x 15 mm symmetrical DIN rail Panel 2 screws, diameter : 4 mm 35 x 7.5 mm symmetrical DIN rail
operating position	Vertical
operating altitude	2000 m
output coupling	Parallel Series
name of test	Harmonic current emission conforming to EN/IEC 61000-3-2 Conducted emissions on the power line conforming to EN 55022 Class B Electrostatic discharges conforming to EN/IEC 61000-4-2 Emission conforming to EN 50081-1 Induced electromagnetic field conforming to EN/IEC 61000-4-6 Primary outage conforming to IEC 61000-4-11 Radiated electromagnetic field conforming to EN/IEC 61000-4-3 Radiated emissions conforming to EN 55022 Class B Rapid transient conforming to IEC 61000-4-4 Surge conforming to EN/IEC 61000-4-5
status LED	1 LED green for output voltage
depth	59 mm
height	100 mm
width	54 mm
product weight	0.195 kg

Environment
product certifications	TUV 60950-1 CCSAus CSA 22-2 No 950 RCM KC CULus 508 EAC
standards	CSA C22.2 No 60950-1 UL 508
environmental characteristic	EMC conforming to EN 55022 Class B EMC conforming to EN 61000-6-3 EMC conforming to EN/IEC 61000-6-2 EMC conforming to EN/IEC 61204-3 Safety conforming to EN/IEC 60950-1 Safety conforming to SELV
IP degree of protection	IP20 conforming to EN/IEC 60529
ambient air temperature for storage	-40...70 °C
relative humidity	0...90 % during operation 0...95 % in storage
overvoltage category	Class II conforming to VDE 0106-1
dielectric strength	Between input and output
MTBF reliability	406032 H with MIL-HDBK-217F calculation method
