Schneider ATV71H037M3 Variable speed drive ATV71 - 0.37kW-0.5HP - 240V - EMC filter-graphic terminal
| range of product |
Altivar 71
|
|
|---|---|---|
| product or component type |
Variable speed drive
|
|
| product specific application |
Complex, high-power machines
|
|
| component name |
ATV71
|
|
| motor power kW |
0.37 kW at 200...240 V 3 phases
|
|
| motor power hp |
0.5 hp at 200...240 V 3 phases
|
|
| motor cable length |
<= 50 m Shielded cable
<= 100 m Unshielded cable |
|
| power supply voltage |
200...240 V (- 15...10 %)
|
|
| network number of phases |
3 phases
|
|
| line current |
3.1 A for 240 V 3 phases 0.37 kW / 0.5 hp
3.5 A for 200 V 3 phases 0.37 kW / 0.5 hp |
|
| EMC filter |
Integrated
|
|
| assembly style |
With heat sink
|
|
| apparent power |
1.3 kVA at 240 V 3 phases 0.37 kW / 0.5 hp
|
|
| prospective line Isc |
<= 5 kA, 3 phases
|
|
| nominal output current |
3 A at 4 kHz 230 V 3 phases 0.37 kW / 0.5 hp
|
|
| maximum transient current |
4.5 A for 60 s 3 phases 0.37 kW / 0.5 hp
4.9 A for 2 s 3 phases 0.37 kW / 0.5 hp |
|
| output frequency |
0.1...599 Hz
|
|
| nominal switching frequency |
4 kHz
|
|
| switching frequency |
1...16 kHz adjustable
4...16 kHz with derating factor |
|
| asynchronous motor control profile |
ENA (Energy adaptation) system for unbalanced loads
Flux vector control (FVC) with sensor (current vector) Sensorless flux vector control (SFVC) (voltage or current vector) Voltage/frequency ratio (2 or 5 points) |
|
| type of polarization |
No impedance for Modbus
|
