Schneider LXM32MD85N4 Motion Servo Drive
The Schneider LXM32MD85N4 Motion Servo Drive is an advanced and highly efficient solution designed to meet the demanding requirements of industrial motion control applications. Engineered with precision and reliability in mind, this servo drive empowers machinery with unparalleled performance and accuracy.
Key Features:
High Performance: The LXM32MD85N4 boasts a remarkable performance profile, delivering precise control and rapid response times. Its advanced servo control algorithms ensure optimal motion control in complex industrial environments.
Versatility: This servo drive is compatible with a wide range of motor types, offering flexibility in application across various industries and motion control systems.
Intelligent Design: Featuring an intuitive interface and comprehensive software tools, configuring and fine-tuning this servo drive is seamless. Its adaptive control functions optimize performance based on load conditions, ensuring maximum efficiency.
Robust Build: Built to withstand rigorous industrial environments, the LXM32MD85N4 is engineered with durable components, ensuring long-term reliability and consistent operation.
Safety Standards: Compliant with stringent safety standards, this servo drive prioritizes operator safety without compromising on performance.
Technical Specifications:
- Voltage Range: 380-480V
- Power Output: 8.5 kW
- Communication Interfaces: Ethernet, Modbus TCP/IP, CANopen, etc.
- Control Modes: Position, Velocity, Torque
- Protection Class: IP20
- Dimensions: [Insert dimensions here]
- Weight: [Insert weight here]
Applications:
Industrial Automation: Ideal for precision control in robotics, packaging, CNC machining, and more.
Motion Control Systems: Enables high-precision motion control in applications requiring superior performance and reliability.
Material Handling: Enhances efficiency and accuracy in conveyor systems, ensuring smooth and controlled movement.
SEO Optimization:
The Schneider LXM32MD85N4 Motion Servo Drive's unparalleled performance, adaptability, and robustness make it a cornerstone in industrial motion control systems. With its advanced features and adherence to safety standards, this servo drive ensures optimal efficiency and reliability across diverse applications.
Drive your industrial machinery towards enhanced precision and efficiency with the Schneider LXM32MD85N4 Motion Servo Drive.
| range of product |
Lexium 32
|
|
|---|---|---|
| product or component type |
Motion servo drive
|
|
| device short name |
LXM32M
|
|
| format of the drive |
Book
|
|
| network number of phases |
Three phase
|
|
| [Us] rated supply voltage |
200...240 V (- 15...10 %)
380...480 V (- 15...10 %) |
|
| supply voltage limits |
170...264 V
323...528 V |
|
| supply frequency |
50/60 Hz (- 5...5 %)
|
|
| network frequency |
47.5...63 Hz
|
|
| EMC filter |
Integrated
|
|
| continuous output current |
32 A (f = 4 kHz)
|
|
| output current 3s peak |
85 A for 5 s
|
|
| maximum continuous power |
9000 W at 230 V
1600 W at 400 V |
|
| nominal power |
9 kW at 400 V (f = 8 kHz)
0.9 kW at 230 V (f = 4 kHz) |
|
| line current |
3.5 A, THDI of 88 % at 380 V, with external line choke of 2 mH
2.9 A, THDI of 98 % at 480 V, with external line choke of 2 mH 3.6 A, THDI of 174 % at 380 V, without line choke 19.9 A, THDI of 145 % at 480 V, without line choke |
| switching frequency |
4 kHz
|
|
|---|---|---|
| overvoltage category |
III
|
|
| leakage current |
<= 30 mA
|
|
| output voltage |
<= power supply voltage
|
|
| electrical isolation |
Between power and control
|
|
| type of cable |
Single-strand IEC cable (for θ = 50 °C) conductor material:
copper 90 °C ,wire insulation material: XLPE/EPR
|
|
| electrical connection |
Terminal cable 8 mm² AWG 8 (CN8)
Terminal cable 5 mm² AWG 10 (CN1) Terminal cable 5 mm² AWG 10 (CN10) |
|
| tightening torque |
3.8 N.m (CN8)
0.7 N.m (CN1) 0.7 N.m (CN10) |
|
| discrete input number |
2 capture
2 safety 4 logic |
|
| discrete input type |
Capture (CAP)
Logic (DI) Safety (compliment of STO_A, compliment of STO_B) |
|
| sampling duration |
0.25 ms
0.25 ms (DI) for discrete |
|
| discrete input voltage |
24 V DC for capture
24 V DC for logic 24 V DC for safety |
|
| discrete input logic |
Positive (compliment of STO_A, compliment of STO_B) at State 0:
< 5 V at State 1: > 15 V conforming to EN/IEC 61131-2 type 1
Positive (DI) at State 0: > 19 V at State 1: < 9 V conforming to EN/IEC 61131-2 type 1 Positive or negative (DI) at State 0: < 5 V at State 1: > 15 V conforming to EN/IEC 61131-2 type 1 |
|
| response time |
<= 5 ms (compliment of STO_A, compliment of STO_B)
|
|
| discrete output number |
3
|
|
| discrete output type |
Logic (DO) 24 V DC
|
|
| discrete output voltage |
<= 30 V DC
|
|
| discrete output logic |
Positive or negative (DO) conforming to EN/IEC 61131-2
|
|
| contact bounce time |
<= 1 ms (compliment of STO_A, compliment of STO_B)
2 µs (CAP) 0.25 µs...1.5 ms (DI) |
|
| braking current |
50 mA
|
|
| response time on output |
250 µs (DO) discrete
|
|
| control signal type |
Pulse train output (PTO) RS422 <= 500 kHz <= 100 m
Pulse/direction (P/D), A/B, CW/CCW 5 V, 24 V link (open collector) <= 10 kHz <= 1 m Pulse/direction (P/D), A/B, CW/CCW 5 V, 24 V link (push-pull) <= 200 kHz <= 10 m Pulse/direction (P/D), A/B, CW/CCW RS422 <= 1000 kHz <= 100 m |
|
| protection type |
Against reverse polarity :inputs signal
Against short-circuits :outputs signal |
|
| safety function |
STO (safe torque off), integrated
SS1 (safe stop 1), with separated eSM safety card SS2 (safe stop 2), with separated eSM safety card SLS (safe limited speed), with separated eSM safety card |
|
| safety level |
SIL 3 conforming to EN/IEC 61508
PL = e conforming to ISO 13849-1 |
|
| communication interface |
Integrated Modbus
With separated communication card CANopen With separated communication card CANmotion With separated communication card Ethernet/IP With separated communication card DeviceNet With separated communication card I/O |
|
| connector type |
RJ45 (labelled CN7) :Modbus
|
|
| commissioning port |
2-wire RS485 multidrop Modbus
|
|
| transmission rate |
9600, 19200, 38400 bps for bus length of 40 m Modbus
|
|
| number of addresses |
Modbus
|
|
| status LED |
1 LED (red) servo drive voltage
|
|
| signalling function |
Display of faults in 7 segments
|
|
| marking |
CE
|
|
| operating position |
Vertical +/- 10 degree
|
|
| product compatibility |
Servo motor BMH (190 mm, 1 motor stacks)
Servo motor BMH (190 mm, 2 motor stacks) Servo motor BMH (190 mm, 3 motor stacks) Servo motor BMH (205 mm, 3 motor stacks) |
|
| width |
180 mm
|
|
| height |
385 mm
|
|
| depth |
240 mm
|
|
| product weight |
9.6 kg
|
| electromagnetic compatibility |
Conducted EMC at class A group 1 conforming to EN 55011
Conducted EMC at class A group 2 conforming to EN 55011 Conducted EMC at environment 2 category C3 conforming to EN/IEC 61800-3 Conducted EMC at category C2 conforming to EN/IEC 61800-3 Susceptibility to electromagnetic fields at level 3 conforming to EN/IEC 61000-4-3 1.2/50 µs shock waves immunity test at level 3 conforming to EN/IEC 61000-4-5 Electrical fast transient/burst immunity test at level 4 conforming to EN/IEC 61000-4-4 Radiated EMC at class A group 2 conforming to EN 55011 Radiated EMC at category C3 conforming to EN/IEC 61800-3 |
|
|---|---|---|
| standards |
EN/IEC 61800-5-1
EN/IEC 61800-3 |
|
| product certifications |
TÜV
RoHS CSA UL |
|
| IP degree of protection |
IP20 conforming to EN/IEC 60529
IP20 conforming to EN/IEC 61800-5-1 |
|
| vibration resistance |
1.5 mm peak to peak (f = 3...13 Hz) conforming to EN/IEC
60068-2-6
1 gn (f = 13...150 Hz) conforming to EN/IEC 60068-2-6 |
|
| shock resistance |
15 gn for 11 ms conforming to EN/IEC 60028-2-27
|
|
| pollution degree |
2 conforming to EN/IEC 61800-5-1
|
|
| environmental characteristic |
Classes 3C1 conforming to IEC 60721-3-3
|
|
| relative humidity |
Class 3K3 (5 to 85 %) without condensation conforming to IEC
60721-3-3
|
|
| ambient air temperature for operation |
0...50 °C conforming to UL
|
|
| ambient air temperature for storage |
-25...70 °C
|
|
| type of cooling |
Integrated fan
|
|
| operating altitude |
<= 1000 m without derating
> 1000...3000 m with conditions |
