Schneider VW3A3601 Ethercat 2 x RJ45 communication module
| range of product |
Altivar
|
|
|---|---|---|
| product or component type |
Communication module
|
| range compatibility |
Lexium 32
Altivar Process Modular Altivar Machine ATV340 except Sercos drives Altivar Machine ATV320 Altivar Process ATV900 Altivar 32 |
|
|---|---|---|
| product compatibility |
Lexium 32
|
|
| communication port protocol |
EtherCAT
|
|
| electrical connection |
2 connectors RJ45
|
|
| transmission rate |
100 Mbps
|
|
| cable distance between devices |
<= 100 m for 100 Mbps
|
|
| addressing |
Logical addressing
Node addressing Position addressing |
|
| communication service |
PDO and SDO support
Drive profile CiA 402 velocity mode conforming to IEC 61800-7-201 (CiA 402) CANopen over EtherCAT (CoE) |
|
| display type |
1 LED input status
1 LED RUN 1 LED error 1 LED output status |
| standards |
IEC 61800-7-201 (CiA 402)
|
|---|
Schneider VW3A3601 Ethercat 2 x RJ45 communication module
- Brand: Schneider
- Product Code: VW3A3601
- Availability: 1000
Tags: VW3A3601
