Schneider VW3A7738 Braking resistor - 1.4 ohms - 1.5 kW - IP23
| product or component type |
Braking resistor
|
|---|
| range compatibility |
Altivar Process ATV900
|
|
|---|---|---|
| product compatibility |
Variable speed drive ATV930 wall mount 55 kW 200...240 V light
cycle
Variable speed drive ATV930 wall mount 75 kW 200...240 V light cycle |
|
| braking cycle |
Light cycle (heavy duty) : <= 0.8 s braking with 150 % braking
torque for a 40 s cycle
Light cycle (normal duty) : <= 0.8 s braking with 120 % braking torque for a 40 s cycle |
|
| average power available |
1.5 kW at 50 °C
|
|
| ohmic value |
1.4 Ohm
|
|
| electrical connection |
Terminal, clamping capacity: <= 2.5 mm², AWG 12 for temperature
control switch
M12 bar wire for drive |
|
| protection type |
Thermal protection via drive or temperature control switch at
120 °C
|
|
| [Ue] rated operational voltage |
24 V DC
250 V AC |
|
| width |
540 mm
|
|
| height |
445 mm
|
|
| depth |
450 mm
|
|
| product weight |
17 kg
|
| ambient air temperature for operation |
0...50 °C
|
|
|---|---|---|
| ambient air temperature for storage |
-25...70 °C
|
|
| IP degree of protection |
IP23
|
Schneider VW3A7738 Braking resistor - 1.4 ohms - 1.5 kW - IP23
- Brand: Schneider
- Product Code: VW3A7738
- Availability: 1000
Tags: VW3A7738
